launch CRP919E BT Diagnostic Scanner with Bluetooth Supports CAN FD, DoIP and ECU Coding – Global Version

The CRP 919E BT is a new generation of 7-inch automotive intelligent diagnostic equipment featuring superior hardware and high performance. It runs on Android 10.0 with a 2.0GHz quad-core processor, 4GB RAM + 64GB ROM storage, and a high-endurance battery—enabling faster, more stable, and longer-lasting diagnostics. This model includes the latest DBScar VII Bluetooth diagnostic connector, building upon the capabilities of the CRP 919E.

CRP919E BT Key Features

• 1. Equipped with DBScar VII Bluetooth adapter—the Bluetooth version of CRP919E
• 2. Full system diagnosis + 31 reset services + FCA Auto Auth
• 3. Active Test (Bi-Directional Test)
• 4. ECU Online Coding (same coding as X431 V/V+) to activate hidden functions
• 5. Supports CAN FD & DoIP protocols
• 6. Two years free updates, five years warranty, and lifetime free tech support ($165/year after warranty)
• 7. Supports 26 languages: Italian, English, German, Japanese, Russian, French, Spanish, Portuguese, Polish, Turkish, Dutch, Greek, Hungarian, Arabic, Danish, Korean, Persian, Serbian, Finnish, Swedish, Czech, Simplified Chinese, Traditional Chinese
• 8. UK/EU Version for customers in the UK and European countries; Global Version for all other regions
• 9. Supports diagnostics for 100+ car brands
• 10. Compatible with BST360 battery tester
• 11. One-click AutoVIN & AutoScan with diagnosis report and online repair resources
• 12. All-around upgrade over launch CRP909X, XTOO D7, FOXWELL NT809, and Autel MK808S
• 13. Touch screen + physical buttons
• 14. 4-in-1 live data graph with record and playback functionality
• 15. Code Search: quickly retrieves DTC definitions and links to “Google” for additional help and tips

Optional Accessories

VSP-600 VideoScope: Inspect hard-to-reach areas such as the engine, fuel tank, and braking system. Features 6 levels of adjustable brightness and works with launch X-431 scanners or any Android device to stream, view, record, and save images and videos.

Battery Tester (BST360): Assess the health of your vehicle’s battery and electrical system for faster, easier diagnostics.

TPMS (X431 TSGUN): Expands functionality when used with X-431 diagnostic tools—activates all 315/433MHz sensors and supports relearning and programming of LAUNCH sensors.

CRP919E BT vs CRP919E

LAUNCH X431 CRP919E BT ECU Coding Functions

ECU Online Coding

This feature connects directly to OEM servers to retrieve lost coding data. Currently compatible only with VW, Audi, Skoda, and Seat. Supported functions include:

• Acoustical confirmation
• Active rear spoiler
• SiriusXM coding
• Digital speedometer coding
• Start & Stop button coding
• Remote window control unlocking
• Acoustic pedestrian protection
• Active Cruise Control
• Air conditioning setting memory
• Automatic Air Recirculation
• Ambient lighting brightness, and more

Also supports offline coding for Volkswagen, Audi, Mercedes-Benz, BMW, Land Rover, Jaguar, Porsche, and Toyota.

Component Matching

After replacing faulty actuators or specific parts, this function generates a new code to detect and initialize new components—such as matching, relearning, calibration, or adaptive data input. Follow on-screen instructions to clear original ECU memory and input new adaptive data. Works seamlessly with LAUNCH X431 IMMO Plus for stable ECU communication.

Personalization

Unlock hidden features or disable unwanted ones by modifying vehicle codes to:

1. Personalize vehicle settings
2. Unlock vehicle potential
3. Activate advanced functions
4. Disable certain features

Compatible with Mercedes-Benz, BMW, Porsche, and others. Examples include:

• Deactivating Start/Stop function
• Disabling beep on lock/unlock
• Turning off seatbelt warning sounds
• Enabling automatic mirror folding/unfolding

Variant Coding (Offline Programming)

Programs ECUs to support different vehicle variants (e.g., left-hand vs. right-hand drive). Also handles region-specific requirements like mandatory automatic headlights. Activates or deactivates software-driven functions. Compatible with Nissan, Nissan-GTR, Infiniti, Hyundai, and more.

Customize OE Settings (Retrofit/Modification)

Modify default settings to enhance performance and profitability—such as upgrading halogen fog lamps to xenon, installing higher-capacity batteries, fitting larger tires, or adding adaptive cruise control, TPMS, and reversing radar through retrofitting.

Note: ECU Coding is not universally compatible with all vehicles! Please provide your VIN, year, and model via support@chinaobd2.com to verify compatibility before purchase.

Programmable Module Installation

For Ford, Lincoln, and Mazda: When replacing or initializing a new/used module, the CRP919E BT can copy data from the original module and install it onto the new unit to complete replacement.

Online Repair Source

Access online repair guidance including operation tips, DTC help, technology handbooks, and relevant case studies.

Built-in Google Browser

Includes a built-in Google browser for internet access and online resource searches—making diagnostics more convenient and efficient.

Professional All-System Diagnostics

The LAUNCH X431 CRP919E BT performs OE-level diagnostics across full vehicle modules—including ECM (engine), TCM (Transmission), ABS, SRS, EPB, BCM, EPS, HVAC, TPMS, and more. Capabilities include:

• Read/Clear Codes
• Smog Test
• Live Data & Freeze Frame
• EVAP Test
• DTC Lookup & Detection Help
• On-Board Monitor Test
• I/M Readiness Check
• O2 Sensor Test
• Retrieve ECU Information
• Matching & Adaptations
• ECU Coding
• Active Test

Delivering faster and more accurate results across all electronic systems.

Complete OBD2 Functions

Supports all standard OBD2 functions to:

• Turn off instrument fault indicators
• Read/clear codes
• Perform O2 sensor tests
• Check I/M readiness
• Run on-board monitor tests
• Read data streams
• Display freeze frame data
• Conduct EVAP system tests
• Retrieve vehicle info (VIN, calibration ID, verification numbers)

CAN FD & DoIP Protocol Support

The CRP919E BT is the only scanner in its price range supporting CAN-FD and DoIP—ideal for GM vehicles from 2020 onward and other new models. It uses advanced CRC algorithms to handle CAN frames from 8 to 64 bytes, enabling faster data transfer and reduced error risk.

Confirmed compatibility includes:

• Chevrolet Onix (2020–2021)
• Chevrolet Tracker (2020)
• Chevrolet Suburban (2021)
• Chevrolet Tahoe (2021)
• Buick
• Cadillac Escalade (2021)
• GMC Yukon (2021)
• GMC Yukon XL (2021)
• Holden
• Daewoo
• Alpheon
• Ravon
• Pontiac
• Saturn
• Hummer

DoIP (Diagnostics over Internet Protocol)

Uses UDS over TCP/IP and Ethernet for significantly higher data rates than CAN—saving time and cost during complex diagnostics and flash applications. Compatible with:

• BMW (F & G chassis)
• Volvo (2018 and later)
• Land Rover & Jaguar (2017 and later)

Powerful Bidirectional Control (Active Tests)

Enables two-way communication between the scanner and vehicle systems. Technicians can command solenoids and actuators directly—testing component operation without using vehicle controls. Ideal for dealerships, repair shops, and DIY users to efficiently identify and resolve issues.

Frequently used active tests include:

• Evap Tests / Purge Solenoid
• Fuel Injector Test
• Cycling A/C Clutch Relay
• ABS Motor Pump Cycling
• Cooling Fan Test
• Headlamp Test
• Sunroof Operation
• Mirror Adjustment
• Horn Activation
• Radiator Fan Control
• Window Operation
• Light Control
• Door Lock Actuator Test
• A/C Compressor Activation
• Throttle Modulation
• Compression Test
• ACM Solenoid Control
• Fuel Pump On/Off
• A/C Clutch Cycling
• Clutch Coil Test
• Acceleration Device Test
• Oil Pressure Control
• Dynamic Camera Aiming
• Vehicle Level Calibration
• Brake Vacuum Pump
• Inlet/Outlet Valve Tests
• Open Brakes Test
• Parking Brake Motors
• Wheel Speed Sensor Supply

Health Report & Feedback

Generate comprehensive vehicle health reports with one click—includes in-depth inspections and calibrations. Reports can be shared, printed via email, or saved locally on the scanner.

Submit diagnostic issues directly to LAUNCH for expert analysis and troubleshooting solutions.

8-in-1 Live Data Stream

View up to 8 real-time data graphs on one screen—correlating parameters like fuel pressure, battery voltage, misfire data, fuel trims, RPM, and more. Focus on symptom-specific data with ease. Supports merging up to 4 live data streams into one graph and exporting data as CSV for long-term storage and PC analysis.

Auto VIN & Auto Scan

Uses VIN-based Auto VIN technology to instantly identify vehicle brand, year, make, and model with one touch. Combined with Auto Scan, it delivers fast, accurate, and comprehensive diagnostics.

Note: Auto VIN may not work on all vehicles. Manual vehicle selection is always available via the menu.

Note: The CRP919E BT remains fully functional for offline diagnostics after subscription expiration—only online features require renewal.

31+ OE-Level Maintenance Functions

Key maintenance services include:

• Brake Reset: Resets brake pad position after replacement to clear warning lights.
• Oil Reset: Clears oil service light and resets mileage/interval after oil change.
• SAS Reset: Recalibrates steering angle sensor after alignment.
• Battery Matching: Re-matches new battery with power management system.
• ABS Bleeding: Automates brake fluid bleeding—no second technician needed.
• SUS Reset: Levels air suspension height sensor after component replacement.
• TPMS Reset: Resets tire pressure sensors and clears MIL after replacement.
• GEAR Reset: Relearns crankshaft position signal after sensor replacement.
• Injector Reset (Coding): Programs new injector codes into ECU.
• AFS Reset: Calibrates automatic headlight leveling based on speed and posture.
• Throttle Adaptation: Resets throttle actuator to factory defaults.

Beyond the 31 common reset functions in the “Service Function” app, explore over 100 advanced hidden functions via: Local Diagnose → Choose Brand & Year → Automatically Search → System Selection → ECM/BCM/etc. → Special Function

Examples include: ECU Configuration, Seat Weight Sensor Calibration, Language Change, A/F Settings, Fuel Alcohol Composition Reset, EVAP Test, Control Unit Reset, Rain/Light Sensor Calibration, A/C Relearn, VGT Relearn, FRM Reset, Clutch Adaptation, Speed Limit Setup, Electronic Pump Activation, Transportation Mode Disable, and Performance Tire Upgrade.

Additional CRP919E BT Functions

IMMO Key Programming

Supports:

• Add/delete fobs and keyless remotes
• Disable lost keys
• Rewrite smart keys
• Replace knob ignition

Note: Designed for Asian vehicles with basic anti-theft systems. For professional-grade programming, consider the Launch IMMO Plus Key Programmer. Contact us via Amazon messaging or Q/A to confirm compatibility.

VAG Guided Functions

Provides step-by-step instructions for complex tasks (e.g., ECU coding, special functions) on Audi, Volkswagen, Skoda, and Seat—bypassing security access codes and channel numbers.

Battery Voltage Test

Displays real-time battery voltage in the top-right corner of the screen. Replace the battery if voltage falls below normal operating range.

Supported Vehicles: 115+ Brands, 10,000+ Models

• American Cars: Buick, Cadillac, Chevrolet, Chrysler, Dodge, Fiat (Brazil), Ford, GM, Jeep, Lincoln, GM (Brazil)
• European Cars: Abarth, Alfa Romeo, Audi, Bentley, BMW, Bugatti, Citroen, Dacia, IZH, Euro Ford, Ferrari, Fiat, GAZ, Opel (South Africa), Iveco, Jaguar, Lamborghini, Lancia, Land Rover, Maserati, Maybach, Mercedes, Mini, Opel, Peugeot, Porsche, Renault, Rolls-Royce, Rover, Saab, Seat, Skoda, Smart, Sprinter, Vauxhall, VAZ, Volvo, VW, Aston Martin, VW_CV
• Asian Cars: Cura, Daewoo, Daihatsu, Holden (Australia), Honda, Hyundai, Infiniti, Isuzu, Kia, Lexus, Luxgen, Mahindra (India), Maruti (India), Mazda, Mitsubishi, Nissan, Nissan GTR, Perodua, Samsung, SsangYong, Subaru, Suzuki, Tata (India), TL Isuzu, Toyota

Product Specifications

• Operating system: Android 10.0
• Processor: 2.0GHz, quad-core
• Memory: 4GB RAM
• Storage: 64GB ROM
• Display: 7-inch LCD, 1024 × 600 resolution
• Camera: 8MP rear-mounted
• Wi-Fi: 2.4GHz
• Battery: 6300mAh

Package Includes

• 1 × Tablet
• 1 × DBScar VII VCI
• 1 × USB cable
• 1 × OBD main cable
• 1 × US standard power adapter
• 1 × UK standard power adapter
• 1 × EU standard power adapter
