K10 Pro Full Systems Bidirectional Scanner Topology Map Car Scanner support 40+ Reset Service ECU Coding CANFD&DOIP

K10 pro is the perfect solution for global users who demand afFORDable , it is is the Most Comprehensive car diagnostic Tool ,which combines advanced Full system diagnosis+ 40 maintenance function or reset services+ ECU Coding+ Key matching+ Active testing+ Remote support+ Intelligent diagnosis+ Modular expansion+ ADAS calibration+ Topological graph+ Guidance function in one .Android based 10.0 inch big touchscreen tablet, provides you with superior special functions by a Android 10.0 OS, a 2.0GHz 4-core high-efficiency processor, a 4GB RAM+128 GB ROM large memory, and a 12600mAh high-endurance battery.support DOip CAN FD protocol , Enjoy maintenance and meet your needs easily!

Global version:
The global version has no IP restrictions and can be used worldwide.
The global version is exactly the same as the European version function.
if you are in US,Mexico,Brazil,South America, North America, Asia etc ,you need choose Global version

KINGBOLEN K10 PRO Selling Points:

1.【Newly Upgraded Comprehensive Diagnostic Tool】 The KINGBOLEN K10 Pro car scanner performs many advanced functions, including Full System Diagnostics, Topology Map, FCA AutoAuth, ECU Coding, Bi-Directional Control, 40+ Reset Services,and added CAN FD & DoIP Protocols ect. Equipped with a 10'' HD screen, 1280 * 800 Resolution, Android 10.0 OS, 4GB RAM+128GB ROM, 12600mAh/3.85V Battery, Rear Camera 8.0MP, and Magnetically Fixed VCI. Upgraded version of K10，more cost-effective, better choices.

2.【CAN FD & DoIP & FCA AutoAuth】 Built in CAN FD protocol and equipped with DoIP adapter cable, provide high-speed vehicle diagnostic communication and data transfer, working perfectly on GM vehicles produced after 2020, and compatible with BMW F/G Chassis models, for Jaguar & Land Rover after 2017, for Volvo after 2018. Bypass SGM in FCA vehicles for successful OBD2 diagnostics, active test, calibrations,compatible with 2018 and later Chrysler, for Dodge, for Jeep, for Fiat, etc.

3.【OE-Level Full System Diagnosis】 The KINGBOLEN K10 Pro Bluetooth OBD2 Scanner supports full system diagnosis. With one-click scanning of all ECU, it can read/clear fault codes, read real-time data/freeze frame, control module information, and perform testing and reset functions for TPMS, ECM, BCM, ABS, SRS, TCM, BMS, SAS, A/C & RTM systems ect. The K10 Pro scanner supports most vehicles after 1996 over 110+ car brands and 38 global languages (EN, FR, ES, DE, IT, RU, PT, JP, TU, POL...)

4.【Enhanced 40+ Hot Reset Services】 The KINGBOLEN K10 Pro diagnostic scan tool comes with 40+ reset functions, such as TPMS Reset, ABS Bleeding, Oil Reset, Injector Coding, SAS Reset, BMS Reset, Reset Gearbox, AFS Reset, SUNROOF, Break Reset, SUS Rest, Elec.Throttle Relearn, engine Power Balance Monitoring ect. Easily meet your various usage needs. With guidance function, It can provides step-by-step maintenance guide for Volkswagen/for Audi/for Skoda. Offer 2 Years Update.(Valued $800)

5.【Efficient Topology Map Design】 The Topology Map shows the system distribution diagram of the vehicle control module. As the complex communication network is generated into a color coded topology display, you can simply click the module to check the fault and quickly determine the root cause. The diagnosis of the system topology map indicates whether the system is normal, faulty or not equipped, which can simplify the troubleshooting workflow. Perfect for DIY, auto repair shop & home mechanic.

6.【Free V.A.G Guide】skip the step of entering the Security Access Code & Channel Number of VW/Audi/Skoda/Seat vehicles for successful diagnostics.

7.【Powerful Bi-Directional Scan Tool】 The K10 Pro car scanner can perform real time active test that can send commands to the vehicle’s ECU to drive the actuators to work, such as Turn on the radiator fan, modulate the throttle, open/close windows, operate mirrors, turn on interior & exterior lights, sound horn, test door lock actuators etc. Without using the vehicle control system, it can help you quickly find out the bad components and the cause of the fault, which can save you a lot of time.

8.【Advanced ECU Coding】 Equipped with ECU Coding function, performs Offline/Online Coding to match/Initialize components' adaptive data after repairing/replacing some components, and activate Hidden Functions: Personalized Settings to activate high-end functions or disable any annoying features. Offline Coding: Compatible for Mercedes-Benz cars. Online Coding: Compatible for Volkswagen, for Audi and for BMW cars.(Note: Not for all cars, please check compatibility before order.)

9. 【 8+ Add on modules】Support printer, work light, video-scope, battery tester, scope box, thermal image, module dock, wireless TPMS tool, 24v truck HD Package (sold separately)

10. 【 OE-Level car coverage】100+ car brands, 20,000+ models from the US, European, and Asian car markets; still expanding.

11. 【 41 Languages】Support 41 different languages,Support English, Arabic, Bulgarian, Polish, Persian, Danish, German, Russian, French, Finnish, Khmer, Korean, Dutch, Czech, Croatian, Romanian, Bengali, Burmese19, Norwegian, Portuguese, Japanese, Swedish, Serbian, Sinhala, Slovak, Slovenian, Tamil, Thai, Turkish, Urdu, Spanish, Greek, Hungarian, Italian, Hindi, Indonesian, Vietnamese, Traditional Chinese, Chinese, Nepali, Telugu,You can switch any language you want.

KINGBOLEN K10 Pro Service for:

Technician , advance DIY, garage, car dealer, used car dealer, auto repair shop, automotive engineer, diagnostic tech, truck man, automobile tech, home mechanic, DIY beginner, automotive student, backyard mechanic, retired mechanic, weekend DIY, individual.

<<<2025 New Elite Version What Updates have we made in 2025 as pro UPGRADED Version of KINGBOLEN K10 pro:

● 4GB RAM / 128 GB ROM
●Andriod 10.0 Operating System: make you smooth operation, Anti-Slip & AntiGreas e protective sleeve design
●10inch HD IPS Touch Screen: A brighter, Clearer, Larger Screen let you "Deep Dive into Diagnostics"
● OE Level Wireless Intelligent Diagnostics, covering more than 100 car makesTablet with 8.0 MP Pixel Rear Camera Brilliant
●Battery Life: 12600mAh rechargeable battery 3.7V

NEWLY add DOip ,CAN FD protocol,F.C.A AUTOAUTH

√CANFD Protocol Supported- CAN with flexible data rate (CAN FD) overcomes the limitations of the classical CAN bus in terms of data transfer rate. This newer protocol can make the data transfer is much more faster, depending on the network topology.

Compatible for G-M models: for Cavalier, TRAX, Encore, Envision, GL8 (LSY), CT4, CT5 …(2020 and later).(No need to buy adapters,unlike the other tools,ours save your money.)

√DOIP Protocol Supported- With Diagnostics over DoIP, diagnostics introduced over UDS are used over TCP/IP and Ethernet. This newer protocol makes X431 PRO ELITE save both in terms of time and expenses in the case of complex diagnostic tasks and flash applications.

Compatible for B-MW (F&G chassis), for Volvo models (2018 later), for Land Rover &for Jaguar models (2017 later).(No need to buy adapters,unlike the other tools,ours save your money.)

√F.C.A AUTOAUTH-You can Register with AutoAuth to communicate with the F.C.A SGW Authentication System and bypass the SGM, so as to perform diagnostics and clear codes, bi-directional functions, active tests, actuation & relearns without using a bypass cable.(No need to buy adapters.)

Compatible with F.C.A cars made in 2017-2024: For Fiat 500X, 500L, 500BEV,For Toro, For Doblo, For Ducato, For Novo Strada, For Mobi ; For Pacifica; For Dodge Challenger,For Charger,For Journey,For Ram (1000, 1500(DS), 1500(DT), 2500, 3500 Cab Chassis, 3500 Cab Chassis 10K, 3500 Pickup, 4500, 5500, Mexico);For ProMaster City; For Cherokee, For Compass,For Gladiator, For Grand Cherokee (W2, WK), For Grand Commander, For Alfa Romeo Giulia, Giulietta/Stelvio ...

Freely switch between 41 Languages：

English, Arabic, Bulgarian, Polish, Persian, Danish, German, Russian, French, Finnish, Khmer, Korean, Dutch, Czech, Croatian, Romanian, Bengali, Burmese19, Norwegian, Portuguese, Japanese, Swedish, Serbian, Sinhala, Slovak, Slovenian, Tamil, Thai, Turkish, Urdu, Spanish, Greek, Hungarian, Italian, Hindi, Indonesian, Vietnamese, Traditional Chinese, Chinese, Nepali, Telugu

All System Diagnosis

The K10 pro auto code reader is a cost-effective automotive scanner, that offers OE-level diagnoses on all available electronic systems, which can read/clear codes, data stream, read control module information for ECM, ABS, SRS, TCM, EPB, TPMS, SAS, A/C, BMS, ESP systems, etc.

Supports OBD2 Full Functions:It supports OBD ll functions to help you turn off the annoying instrument fault indicator and also can read/clear codes, O2 sensor test, I/M readiness, On-board monitor test, read data stream, display freeze frame data, EVAP system test, retrieve vehicle information (VIN, calibration ID, calibration verification numbers)

Supports Full System Diagnostics: engines/Auto Transmission/Airbags/IMMObilizer/Key Coding/ABS/Cruise Control/Instruments/Self Leveling Suspension systems Seats / Doors / Gateway / Steering Angle / Air Suspension / Body Systems / Electronic Power Steering & Motor Assisted / Power Steering / Tyre Pressure / Rain Sensors / 4WD System Stabilizer/Intelligent Parking Assist/Door Motors/Audio systems/Air Conditioning/Tiptronic/Anti Theft/Soft Top/Headlamp Leveling/Central Locking/Automatic Clutch/DP.F Reset Electric Windows / Plip Programming / Heated Rear Window / Xenon Headlights / Wash Wipe / Fuel Burning Heater / Transfer Box / Seat Memory / Oil Reset / Sliding Doors / Electronic Throttle Navigation System / Rollover Sensor / Cruise Control / Multi Function Steering Wheel / Aux Heating / Electronic Parking Brake / Clutch Electronics ... and more.

OE-LEVEL Advanced Functions：

●Component Matching: Compatible for Volkswagen / for Skoda / for Seat /for BMW / for GM / for FORD / for Opel / for Mazda / for Fiat / for Honda / for Nissan / for Hyundai / for KIA/ for Subaru etc.
●Online Coding: Compatible for Volkswagen / for Audi / for Benz / for BMW / for Seat / for PORSCHE etc.
●Online Account Login Service: Compatible for Volkswagen / for Audi / for SKODA / for Seat etc.
●Online Calibration: Compatible for Volkswagen / for Audi / for SKODA / for Seat etc.
●Online Parameterization: Compatible for Volkswagen / for Audi / for SKODA / Seat etc.
●Anti-theft IMMO Service: Compatible for Volkswagen / for Audi / for SKODA / Seat etc.
●Guided Functions: Compatible for Volkswagen / for Audi / for SKODA / for Seat etc.
●Power Balance: Compatible for Chrysler / for GM / for FORD etc.
●Coding Module Installation: Compatible for FORD / for Mazda etc.
●Flash Hidden Functions: Compatible for BMW / for PORSCHE / for Toyota / for Subaru etc.
●SCN Coding for Benz

ECU Coding:

* Online Coding: K10 PRO scan tool can directly access the online vehicle repair data to do high-level repairs.

* Offline Coding: read the code from the original module, and then write the code for the new module,for example ,write a VIN to new ECU.

* Component Matching:Matching,relearn ,Cali-b-ration, or initia-lization adaptive data for certain components after repair or replacements,such as: suspension cali-bration ,seat matching ,sunroof initia-lization,gearbox matching,injector cali-bration, transmission adap-tion.Delete Adapt-ation Data, Tank Cali-b-ration,Height sensor system cali-bration,PSM Sensor Cali-b-ration ,etc.

* Re-trofit/Modi-fication: for example, re-trofit battery with different type, Upgrading the headlights, taillights, and interior lighting to LED lights,etc.

* Unlock the hidden features:for example,disable auto start-stop, disable daytime running light, disable safety belt chiming ,delete transport mode,delete transmission adaptive value.setting speed limits,etc.

Active Test &Bi-directional control

Bi-Directional Control capability and is capable of performing Active Tests to access vehicle-specific subsystems and component tests. The tester outputs commands to the ECU to drive the actuators in order to determine the integrity of the system or parts by reading the ECU data, or by monitoring the operation of the actuators .For example , K10 pro have the ability to actuate relays, injectors, coils, or perform system tests, etc. Also it will actuate solenoids valve and actuators for active testing to identify the error easily moreover. The bidirectional functions are quite extensive. even open an e.g.r. valve and seeing the difference in idle response and oxygen sensor voltage. Please note: Active tests are NOT universal for all vehicles, check compatibility with VIN number before purchase. Active tests vary depending on the manufacturer, year, and model, and only the available tests display in the menu.

41+ Reset Functions

( pls note different reset function supports different cars , also supports some cars , not for all cars , pls contact us check the detailed car list , you also can check in the link directly : https://h5.thinkcar.com/coverage/all ）

1> Oil Reset Service

This function enables you to reset the oil service for the engine oil life system,which calculates an optimal oil life change interval depending on the vehicle driving conditions and weather events.
lt needs to be performed in the following cases:
1. lf the service lamp is on, run car diagnostics first for troubleshooting.Afterthat, reset the driving mileage or driving time, so as to turn off the servicelamp and enable a new driving cycle.
2. lf the service lamp is not on, but you have changed the engine oil or electric
appliances that monitor oil life, you need to reset the service lamp.

2> Electronic Throttle Position Reset

This function enables you to make initial settings to throttle actuators andreturns the learned values stored on ECU to the default state. Doing so canaccurately control the actions of regulating throttle (or idle engine) to adjust theamount of air intake.

3> Steering Angle Calibration

This function enables you to reset the steering angle,after replacing thesteering angle position sensor,replacing steering mechanical parts (such assteering gearbox,steering column, end tie rod, steering knuckie), performingfour-wheel alignment, or recovering car body.
To reset the steering angle, first find the relative zero point position for thecar to drive in straight line. Taking this position as reference,the ECU cancalculate the accurate angle for left and right steering.

4> Battery Maintenance System Reset

This function enables you to perform a resetting operation on the monitoringunit of vehicle battery, in which the original low battery fault information will becleared and battery matching will be done.
lt needs to be performed in the following cases:
1. The main battery is replaced.
2. The battery monitoring sensor is replaced.

5> ABS Bleeding

This function allows you to perform various bi-directional tests to check theoperating conditions of Anti-lock Braking System(ABS).
lt needs to be performed in the following cases:
1. When the ABS contains air.
2. When the ABS computer, ABS pump, brake Master cylinder, brake cylinder,brake line, or brake fluid is replaced.

6> Electronic Parking Brake Reset

This function enables you to reset the brake pad after replacing the brake pad.lt needs to be performed in the following cases:
1.The brake pad and brake pad wear sensor are replaced.
2.The brake pad indicator lamp is on.
3.The brake pad sensor circuit is short, which is recovered.
4.The servo motor is replaced.

7> Diesel Particulate Filter (DPF) Regeneration

This function enables you to clear PM(Particulate Matter) from the DPF filterthrough continuous combustion oxidation mode (such as high temperatureheating combustion,fuel additive or catalyst reduce PM ignition combustion)to stabilize the filter performance.
lt needs to be performed in the following cases:
1. The exhaust back pressure sensor is replaced.
2. The PM trap is removed or replaced.
3. The fuel additive nozzle is removed or replaced.
4. The catalytic oxidizer is removed or replaced.
5. The DPF regeneration MlL is on and maintenance is performed.
6. The DPF regeneration control module is replaced.

8> Gear Learning

This function enables you to perform tooth learning for the car, to turn off the MIL.
lt needs to be performed in the following cases:
1. After the engine ECu, crankshaft position sensor, or crankshaft flywheel isreplaced.
2. The DTC 'tooth not learned' is present.

9> IMMO Service

This function enables you to perform the anti-theft key matching function, sothat the immobilizer control system on the car identifies and authorizes remotecontrol keys to normally use the car.
lt needs to be performed in the following cases:
When the ignition switch key, ignition switch,combined instrument panel,ECU,BCM, or remote control battery is replaced.

10> Injector Coding

This function enables you to write injector actual code or rewrite code inthe ECU to the injector code of the corresponding cylinder，so as to moreaccurately control or correct cylinder injection quantity.
lt needs to be performed in the following cases:
After the ECu or injector is replaced.

11> TPMS Reset

After the tire pressure MIL turns on and maintenance is performed, the tire pressure resetting function must be performed to reset tire pressure and turn off the tire pressure MIL. Tire pressure resetting must be performed after maintenance is performed in the following cases: tire pressure is too low, tire leaks, tire
pressure monitoring device is replaced or installed, tire is replaced, tire pressure sensor is damaged, and tire is replaced for the car with tire pressure monitoring function.

12> Suspension Calibration

This function enables you to adjust the height of the body.
lt needs to be performed in the following cases:
1. When replacing the body height sensor， or control module in the airsuspension system.
2. When the vehicle height is incorrect.

13> AFS (Adaptive Front-lighting System) Reset

This function enables you to initialize the adaptive headlamp system.

14> Gearbox Matching

This function enables you to complete the gearbox self-learming to improvegear shifting quality.
lt needs to be performed in the following cases:When the gearbox is disassembled or repaired.

15> Sunroof Initialization

This function enables you to set the sunroof lock off,closed when it rains,sliding / tilting sunroof memory function, temperature threshold outside the caretc.

16> EGR Adaption

This function is used to learn the EGR(Exhaust Gas Recirculation) valve afterit is cleaned or replaced.

17> Odo Reset

ODO reset is to copy, write, or rewrite the value of kilometers in the chip of odometer by using a car
diagnostic computer and data cable, so that the odometer shows the actual mileage.
Usually when the mileage is not correct due to the damaged vehicle speed sensor or odometer failure, it
is necessary to do ODO reset after maintenance.

18> Airbag Reset

This function resets the airbag data to clear the airbag collision fault indicator. When the vehicle collides and the airbag deploys, the corresponding fault code of the collision data appears, the airbag indicator lights up, and the fault code cannot be cleared. Since the data inside the airbag computer is disposable,
it is required that all new accessories must be replaced, but after performing this function, the data of the airbag computer can be recovered and the fault code can be cleared, the airbag light will go out, and the airbag computer can continue to use.

19> Transport Mode

In order to reduce power consumption, the following functions may be disabled, including limiting the vehicle speed, not waking up the door opening network, and disabling the remote-control key, etc. At this time, the transport mode needs to be deactivated to restore the vehicle to normal.

20> A/F Reset

This function is applied to set or learn Air/Fuel ratio parameters.

21> Stop/Start Reset

This function is used to open or close the automatic start-stop function via setting the hidden function in ECU (provided that the vehicle has a hidden function and supported by hardware).

22> NOx Sensor Reset

NOx sensor is a sensor used to detect the content of nitrogen oxides (NOx) in engine exhaust. If the NOx fault is re-initialized and the NOx catalytic converter is replaced, it is necessary to reset the catalytic converter learned value stored in the engine ECU.

23> AdBlue Reset (Diesel Engine Exhaust Gas Filter)

After the diesel exhaust treatment fl uid (car urea) is replaced or filled up, urea reset operation is required.

24> Seat Calibration

This function is applied to match the seats with memory function that are replaced and repaired.

25> Coolant Bleeding
Use this function to activate the electronic water pump before venting the cooling system.

26> Tyre Reset

This function is used to set the size parameters of the modifi ed or replaced tire.

27> Windows Calibration

This feature is designed to perform door window matching to recover ECU initial memory, and recover the automatic ascending and descending function of power window.

28> Language Change

This function is used to change the system language of the vehicle central control panel.

29> AC System Relearn/Initialization

If the ECU or actuator of the vehicle air conditioner is replaced, or the memory of the ECU memory is lost, air conditioner initialization learning is needed.

30> Intelligent Cruise Control System

For replacement of intelligent cruise control system of vehicle and matching after repairing.

31> Engine Power Balance Monitoring

At the power stroke of each cylinder, power balance monitors crankshaft acceleration, thus determining the relative power provided by each cylinder.

32> Gas Particulate Filter Regeneration

After long-term use of the particle catcher, fuel consumption can be increased, engine output power can be decreased, then in this case, the GPF needs to be replaced or regenerated.

33> Motor Angle Calibration

There is a deviation between the rotor position detected by the angle position sensor of the motor and the actual rotor magnetic field position, so it is necessary to calibrate the motor angle.

34> High Voltage Battery Diagnostics

For diagnosis and state information detection on high-voltage accumulator.

35> Clutch Matching

This function is for clutch pedal position or switch learning for adaptive clutches. After ECU replacement, gearbox replacement or removal, and clutch replacement, this function learns the contacts and positions where the clutch starts to transmit engine torque.

36> ECU Reset

After performing the encoding function of some systems, it is necessary to implement the control unit reset; sometimes the data of bad driving habits can also be eliminated by resetting the ECU.

37> FRM Matching

The Footwell Module is referred to as FRM. It is composed of a circuit module with a CPU. Its main function is to control the doors, windows, headlights and communication system of the vehicle. FRM Matching is used to clear the short circuit fault of the light.

38> Gateway Module Data Calibration

A "gateway" is designed between the two independent buses of the power system CAN and the body system CAN to realize the resource sharing between each CAN and feed back the information of each data bus to the instrument panel. After replacing the gateway control unit, there may be inconsistencies such as VIN, so it needs to be calibrated.

39> Rainfall Light Sensor

The rain sensor is used to adjust the wiper frequency, and the light sensor adjusts the light intensity of the automatic headlights according to the ambient light and darkness. This function can adjust the initial parameters.

40> Turbocharging Matching

The parameters that aff ect the engine boost mainly include the air flow of the engine, the boost pressure ratio, the effi ciency of the compressor, and the temperature of the engine exhaust gas. Replaced parts such as turbine, its initial value must be reset, and, if fi ne-tuning is required, make some settings through this function.
................

KINGBOLEN K10 PRO Supports Topology Map ,improving your working efficiency highest than ever.

* Introducing the revolutionary function of topology mapping in automotive diagnostic products! Say goodbye to guesswork and hello to precision with our advanced technology that allows you to easily identify and locate faults in your vehicle's electrical system. With topology mapping, you can quickly and accurately diagnose issues, saving you time and money on costly repairs.

* Our cutting-edge diagnostic tools provide a comprehensive view of your vehicle's electrical system, giving you a detailed map of all the components and their connections. This allows you to quickly pinpoint any faults and troubleshoot with ease. Whether you're a professional mechanic or a DIY enthusiast, our topology mapping feature is a game-changer that will take your diagnostic capabilities to the next level.

* Don't settle for outdated diagnostic tools that leave you guessing. Upgrade to our topology mapping technology and experience the future of automotive diagnostics today. With our products, you'll have the power to diagnose and fix problems with confidence, ensuring your vehicle runs smoothly and efficiently. Try it now and see the difference for yourself!

The Other Function of KINGBOLEN K10 PRO :

1. Remote Assistance

In this function, you can request remote assistance through third-party software. By sending your device ID number to the remote technician or after-sales personnel, you can authorize the other party to remotely operate the device, so as to guide you to the problems encountered in the process of using the device.

2. File

It is used to record and establish the fi le of the diagnosed vehicles. The fi le is created based on the vehicle VIN and check time, including all VIN-related data such as diagnostic reports, data stream records and pictures.

3. Repair Info

Tap "Repair Info" on the homepage, the following page will appear :

OBD Fault Code Library
Coverage List
Learning materials
User Manual
Diagnostic Feedback

KINGBOLEN K10 PRO Supports various extended modules

( All the models need buy additionally )

1. ADAS Function : need works with KINGBOLEN ADAS TOOL

2. Printer : Thermal printer, can be used with the device or moduledock, quickly print diagnostic reports anytime and anywhere.

3. Video Scope

4. Scope Box

5. Wireless TPMS TOOL

KINGBOLEN K10 PRO Supports Car List :

For Aston Martin, For Audi, For AUSTFORD, For AUSTHOLDEN, For VIN self-identification, For Beijing Auto, For Mercedes-Benz, For BMW, For BXFIAT, For BXGM, For Changan Automobile, For GreatWall, For Changhe, For Chrysler/For Dodge/For Jeep, For Citroen, For CMC, For Daewoo, For Daihatsu, Demo , For Dongfeng Xiaokang, For Dongfeng Xiaokang, For Southeast Auto, For DR, For Electronic Control Assistant, EOBD , For Ferrari, For Fiat, For BYD, For Fuso, For Beiqi Foton, For GAZ, For GM, For Hafei, For Geely, For Brilliance Xinyuan, For Hino, For Haima, For Honda, For Brilliance Jinbei, For Hyundai, For Hyundai PLUS, For IKCO, For India Force, For INDIANMAHINDRA, For INDIANMARUTI, For INDIANTATA, For Jiangling Motors, For Iveco, For IZH, For JAC, For Gonow, For Xiamen Golden Dragon, For Kowloon, For Isuzu, For KIA, For KIA Korea, For Land Rover, For Leapmotor, For Lifan, For Wuling Baojun, For Luxgen, For Mahindra, For MalaysiaPERODUA, For MALAYSIAPROTON, For Maruti, For Maserati, For SAIC MAXUS, For Mazda, For Mitsubishi, For MVM, For Nissan, For Opel, For PAZ, For PERODUA, For PEUGEOT, For PORSCHE, For PROTON, For CHERY, For QOROS, For RENAULT, For ROVER, For SAAB, For SAIC MG, For SAIPA, For SAMSUNG, For SEAT, For SEAZ, For GM China, For Skoda, For Smart, For Spark, For Mercedes-Benz Commercial Vehicles, For Ssangyong, For Subaru, For Suzuki, For SWM, For TATA, For Tesla, For Toyota, For GAC Trumpchi, For UAZ, For Ford, For VAZ, For Volvo, For Volkswagen, For WEILI, For Tianjin FAW, For Xinkai, For ZAZ, For Zhongshun, For Zotye, For ZTE Auto

KINGBOLEN K10 PRO Parameter :

Tablet size: 10 inches, 1280*800
System version: Android 10
CPU version: MT8365
Running memory: 4GB
Storage memory: 128GB
Battery capacity: 3.7V/12600mAh,
Camera: rear 800W
Wifi network: 2.4GHz, 5.0Ghz dual-band
Charging power: 5.0V -- 2.5A 12.5W

K10 pro Packing List :

1Pc * KINGBOLEN K10 pro Tablet
1Pc * Ediag pro conntor
1PC * DOIP cable
1PC * RJ45 Network Cable
1PC * USB2.0 to10/100M Network Cable
1PC * type c cable
1PC * Diagnostic Extension Cable
1PC * 3-in-1 Charger(Matched withU.S.. U.K. and European plugs)
1PC * User Manual
1PC * Packing List
1PC * Password Letter
