Autel MaxiAP AP2500E Scanner Bluetooth Code Reader All-System, CAN FD, 5 Hot Resets, AutoVIN, Check Engine Light, Car Code Reader for Android/iOS

Autel AP2500E Bluetooth Code Reader

MaxiAP AP2500E is a powerful and essential scan tool specially designed for individual car owners. It includes a Bluetooth (BT) dongle and the Autel MaxiAP Diag app. Plug the Bluetooth dongle into a vehicle OBDII port and connect it with a mobile device via Bluetooth. Download the Autel MaxiAP Diag app to obtain free support for one vehicle brand, including health reports, maintenance advice, TSB/Recall information, and more. It adds additional vehicle brands with in-app purchases.

Autel AP2500E: Upgrade of AP200 Bluetooth Code Reader, Cost The Same Bucks & Get More Functions

Why do we choose the Autel AP2500E? Not only can you diagnose and address minor car problems by yourself, but you can have a better sense of how much a car repair will cost before you take your vehicle to a mechanic. Autel AP2500E features great usability (BT connection), app experience (intuitive interface), and available functionality (all-system check + hot special functions) but also low-cost under 60 bucks (59 Bucks).

Autel AP2500E Highlights:

1. Portable Size: Half the size of a hand. Easy to carry everywhere and put in your pocket.
2. 33ft. Bluetooth Diagnostics: Plug to use without being tethered to the driver seat.
3. Auto VIN: Automatically identify domestic, foreign, and luxury vehicles within 60 seconds.
4. All-System Scanning: Scan/diagnose all available systems, not only include 4 commonly used systems (engine, AT, SRS, ABS). Perform all-around code reading & clearing and quickly locate problems.
5. 5 Reset Functions: Same as the MK808 series diagnostic tablet, AP2500E bluetooth Code Reader obd2 comes with 5 hot special functions oil maintenance, TPMS（just read tire pressure from ECU）, wiper replacement, BMS reset, EV battery diagnostics.
6. OBD II Full Tests: Do in-depth checks for the ECM module and make enough preparation for the annual s~m~o~g check.
7. 45+ Brand Coverage: Work with 1996-2024 cars and provide one car model software for lifetime free use.
8. Android/iOS: Entirely compatible with Android/iOS smartphone devices. Start diagnosis when pulling your cell phone out of your pocket.
9. Exclusive APP: The user interface is well-designed and simple to follow with straightforward instructions.
10. 3 Languages: English/French/Spanish diagnostic language installed in the vehicle software for free change.

All System Diagnostics: One-click Scan All Systems, Minute to Locate Problems

Some Bluetooth code readers obd2 focus on the engine system only, but the Autel AP2500E auto code reader does more than check engine codes. Autel MaxiAP AP2500E allows you to perform in-depth checks for all systems such as engine, Powertrain, Steering Angle, Brake, Airbag, ABS, and more, helping you read/clear fault codes and giving you sufficient DTC information. All diagnostic interfaces are intuitive - even for the novice.

Auto VIN: Rarely configured on a 60 bucks code reader. Automatically Identify Tested Car. Automatic identification + manual input makes you no more waste time seeking vehicle information (make, model, year).
Smooth System Diagnostic Process: Function as OE-level diagnostics, AP2500E scans all vehicle systems, reads codes, displays fault codes, clears fault codes, turns off the lights, etc.
Diagnostic Report Generating: After scanning all systems, a dashboard with specific vehicle health ratings, the total number of DTCs, and vehicle condition data will be presented. The available data can be the most effective & accurate reference to get the right repair fix.
Detailed DTCs Displaying: The DTC code, status, and definition of each DTC are listed under the System DTCs.
Free System Diagnostics: The software for one vehicle brand is free and permanently valid for the Custom Scan and Full Scan.

OBDII Full Tests: Find Out The Exhaust Problems Before Annual Inspection Timely

When a vehicle's computer identifies a problem with a part of the exhaust control system it stores a Diagnostic Trouble Code that may cause your vehicle to fail the state exhaust inspection. So it is essential to do a pre-check for engine-related systems by using an OBDII code reader bluetooth. Pre-check saves you time and money. AP2500E check engine light code reader helps to find problems quickly, even ones that aren't visible before they get costly.

O2 Sensor Test: Retrieve and view O2 sensor monitor test results for the most recently performed tests from the vehicle’s on-board computer. (Note: If the vehicle uses a controller area network (CAN) protocol to communicate, this function is not supported by the vehicle).
Live Data Stream: Show the information of continuous data stream from a vehicle in a live graphic (waveform) display.
Freeze Frame: Read and display live ECU/PCM data stream, plotting functions graphically and storing freeze frame data.
Read Code: Show the detailed description of DTCs(current, pending, and permanent codes)
Erase Code: Clear DTCs after repairing and turn off the check engine light.
I/M Readiness: Check the readiness of the various exhausts-related systems on the vehicle.
On-Board Monitor Test: Retrieve and display test results of exhaust-related powertrain components and systems.
EVAP System Test: Initiate a leak test for the vehicle evaporator system.
Vehicle Information: Display the information such as VIN (Vehicle Identification Number), CID (Calibration ID), CVN (Calibration verification number), etc.
Component Test: Sent command to test vehicle components’ functionality.

Small-Sized AP2500E Code Reader with 5 Service Functions Saves Your Expensive Repair Fee

Typically simple oil maintenance service being taken to the mechanic will cost you 100-200 bucks per visit. A 59-priced Autel AP2500E bluetooth code reader will pay for itself very quickly with a single oil reset maintenance. Besides the extra 4 special functions (TPMS-just tire pressure, Wiper Replacement, BMS Reset, and EV Battery) also do a lot for your home repair. Its plug-and-play features make it useful for beginners and experts alike.

O-i-l Reset: This function allows you to perform resets for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle’s driving conditions and climate. The Oil Life Reminder must be reset every time the oil is changed, so the system can calculate when the next oil change is required. About 5 minutes of work done on your own can save at least 100 bucks and more time.
Tire Pressure Monitor Reset: Quickly read the tire pressure from the vehicle’s ECU. AP2500E allows you to adjust the correct tire pressure indirectly and reset the tire pressure ECU to start a new driving trip.
Wiper Reset: This function provides methods for the replacement of wiper blades, which include the operation of parking the wiper blades in the appropriate position, as well as disassembling and assembling the wiper blades.
BMS Reset: AP2500E code reader bluetooth will evaluate the vehicle battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle. You can register the battery replacement with the vehicle computer after replacing a new battery.
EV Battery: Specially designed for electric vehicles (EVs). After establishing communication with an electric vehicle, the AP2500E auto code reader diagnostic & reset is able to read the battery pack data including SOC, SOH, total voltage, total current, pack voltage delta, and temperature and provide battery maintenance advice.

OBD Live Data Stream: Monitor Your Car's Health At All Times With Your Cell Phone

Autel AP2500E code reader features a graphic vehicle live data stream that makes it easier for DIY users to interpret the data, diagnose problems, monitor vehicle health, and optimize the repair process. For instance, you can use live data graphs to check fuel consumption, compare ignition timing readings, observe oil temperature, and review the vehicle speed. All is well for effectively troubleshooting problems. Here's a breakdown of practical functionalities:

Reading Various Data: AP2500E auto code reader reads live data from vehicles including Engine RPM, Engine Coolant Temperature, Vehicle Speed, Intake Air Temperature, Calculated Load Value, Air Flow Rate, etc., which can be used for vehicle health analysis.
Monitoring Vehicle Health: Graphical representations can be more intuitive than tables of numbers, especially when monitoring multiple parameters simultaneously. Patterns, trends, or anomalies in the data may be more apparent, helping technicians identify issues or abnormalities in the vehicle.
Customizing Data Options: Depending on the engine system, users might have the ability to customize the graphical representation of the live data. This could include choosing which parameters to display, adjusting the time scale, or selecting specific types of graphs.
Diagnosing Vehicle Everywhere: Due to its portable size, you can operate the Autel MP2500E car code reader for iPhone to scan vehicle systems and monitor vehicle data/conditions.

Extensive Vehicle Coverage & Language Coverage

Extensive Vehicle Coverage & Language CoverageExtensive Vehicle Coverage & Language Coverage
Autel AP2500E bluetooth obd2 scanner covers 45+ car brands and works on most OBDII compliant vehicles from 1996 to 2024. Intelligent plug-to-play scan tool functions on various passenger cars, EVs, pickups, SUVs, minivans, etc. Technology power enables you to solve basic repairs on your own but also saves cost & money on going to mechanics.

1)Powerful Vehicle Coverage for Global Users & Car Models

Europe: BMW, Mini, Rolls Royce, Volvo, Polestar, Audi, VW, Bentley, Bugatti, Lamborghini, Mercedes-Benz, Maybach, Sprinter, Smart, Fiat, Alfa Romeo, Maserati, etc.
America: Cadillac, Chevrolet, Buick, GMC, Saturn, Pontiac, Hummer, Oldsmobile, Ford, Lincoln, Mercury, Chrysler, Dodge, Jeep, RAM, SRT, etc.
Asia: Mazda, Honda, Acura, Hyundai, KIA, Genesis, Nissan, Nissan-GTR, Infiniti, Toyota, Lexus, Scion, Subaru, Mitsubishi, etc.

2)Compatible with CAN FD, Autel AP2500E runs 5x faster speed on GM models (2019 and later).

3)Free diagnosing your vehicles for a lifetime. (ONLY valid for one car model software you have chosen ).

4)Cheaper subscription fee for global Autel Users. If you have diagnostic needs for other car models, you can use it for 12 months for only 21.99 bucks.

5)4 Language supports: English/French/Spanish/Chinese

Common Question & Answer: You May Find Solutions for Your Issues In Here

Q1: Does this AP2500E obd2 bluetooth scanner only support one car model?
A: AP2500E only provides lifetime Free use for ONE vehicle model. If you want to diagnose another vehicle model, you can pay 21.99/year for related vehicle software at App Store or Google Play.

Q2: If I change my phone device or uninstall the “Autel MaxiAP Diag” APP, do I still need to purchase the car software again?
A: No. All the diagnostic history & purchases are stored in your Autel account. Log in to your account can use your code reader normally.

Q3: Does this unit work on my car?
A: 1) AP2500E supports 45+ common brands worldwide. You can send the vehicle VIN to us to check compatibility before purchase.
2) Or check the product car model compatibility table in the product document column, enter your car model to see if it is compatible.

Q4: Why can't I download the updated software?
A: You can try to download software on Another phone device. If can not, message us.

Q5:Why can't I connect to Bluetooth?
A：1) Please note: Android/iOS users connect to Bluetooth in “Autel MaxiAP Diag” APP.
2) If pairing fails, please try to forget Bluetooth and pair again. 3) Contact our after-sales team and we will provide you with a solution

Q6: Do I need to spend a lot on subscriptions?
No, and compared to MX808 and other expensive annual subscriptions, it's very cost-effective! Don't misunderstand AP2500, give it some trust!
If you diagnose one car, you can use it no-fe.e for lifetime. If you have many cars and they are different brands! starting from the second brand car, it is only 21.99 per year. If it is the same brand, it is also no-fe.e for life.

Communications	Bluetooth V5.0 + BR/EDR/BLE
Wireless Frequency	2.4 GHz
Input Voltage Range	8 to 24 V DC
Supply Current:	500 mA @ 12 V DC
Operating Temperature	-10 to 50 ℃ (14 to 122 ℉)
Storage Temperature	-20 to 60 ℃(-4 to 140 ℉）
Dimensions (L*W*H)	64.2 mm (2.52") x 45 mm (1.77") x 21.5 mm (0.85")
Weight	34.2 g (0.07 lb.)

Package Includes:

1pc x Autel MaxiAP AP2500E Diagnostic/Service Scan Tool
